| JMC Carrying Plus 3360 Taking the best and most reliable characteristics from its ancestor the Carrying, along with upgrades to the looks and aesthetics, this new Carrying Plus is transporting the JMC brand into the future of light duty trucking
|
| JMC Carrying Plus 3360 Taking the best and most reliable characteristics from its ancestor the Carrying, along with upgrades to the looks and aesthetics, this new Carrying Plus is transporting the JMC brand into the future of light duty trucking
|
ENGINE
Engine Model: Euro II JX493ZQ4A
Displacement (ml) : 2771
Max. Output (kW): Euro II 68
Max. Torque (N·m): Euro II 210
Fuel Tank Capacity (L): 83
Max. Speed (km/h): 100
Displacement (ml) : 2771
Max. Output (kW): Euro II 68
Max. Torque (N·m): Euro II 210
Fuel Tank Capacity (L): 83
Max. Speed (km/h): 100
BASICS
Overall Dimension Cargo body (lxwxh): 5980 x 2050 x 2380
Overall Dimension Box Van (lxwxh): 5980 x 2130x 3085
Rear Cargo Body Size (lxwxh): 4100 x 2050 x 380
Rear Box Van Size (lxwxh): 4080 x 2050 x 2050
Cabin Width Inside (mm): 1830
Cabin Width Outside (mm): 2050
Gross Vehicle Weight (kg): 5995
Curb Weight (kg): 2565
Wheelbase (mm): 3360
Seat Capacity: 3
CONTROL
Gearbox Type: 5F/1R
Power Steering: Yes
Exhaust Brake: Yes
ABS: No
Tire: 7.00R16 12PR
Power Steering: Yes
Exhaust Brake: Yes
ABS: No
Tire: 7.00R16 12PR
EQUIPS
Remote Central Lock
Radio + MP3 + USB
Multi/functional Steering Wheel
Adjustable steering wheel
Air conditioner
Reversing Lock Warning
Co-pilot Sun Visor
Front Fog Lamp
Tilting Cab with notice
High-temperature instrument
Iron Cargo
Cargo Baseboard (Cladding Board)
Radio + MP3 + USB
Multi/functional Steering Wheel
Adjustable steering wheel
Air conditioner
Reversing Lock Warning
Co-pilot Sun Visor
Front Fog Lamp
Tilting Cab with notice
High-temperature instrument
Iron Cargo
Cargo Baseboard (Cladding Board)
| JMC Carrying The Pioneer of cargo transportation in China, JMC Carrying is the best known light duty truck and has been the market leader for decades. With the same classic Isuzu engine, this truck prides itself on its durability.
|
| JMC Carrying The Pioneer of cargo transportation in China, JMC Carrying is the best known light duty truck and has been the market leader for decades. With the same classic Isuzu engine, this truck prides itself on its durability.
|
ENGINE
Engine Model: Euro1 JX49Q1
Displacement (ml) : 2771
Max. Output ( Kw/hp/rpm): Euro1 57 (77)/3600
Max. Torque (N·m): Euro1 172/2000
Fuel Tank Capacity (L): 83
Fuel Consumption ( L/100km): 9
Max. Speed (km/h): 100
Displacement (ml) : 2771
Max. Output ( Kw/hp/rpm): Euro1 57 (77)/3600
Max. Torque (N·m): Euro1 172/2000
Fuel Tank Capacity (L): 83
Fuel Consumption ( L/100km): 9
Max. Speed (km/h): 100
SPECIFICATIONS
Front / Reat Tread (mm): 1385/1425
Min Ground Clearance (mm): 190
Min Turning Diameter: 13.6
Compression Ratio: Euro1 18.2:1
Gearbax Model: Euro1: MSB-5M
Wheelbase (mm): 3360
Seat Capacity: 2
Min Ground Clearance (mm): 190
Min Turning Diameter: 13.6
Compression Ratio: Euro1 18.2:1
Gearbax Model: Euro1: MSB-5M
Wheelbase (mm): 3360
Seat Capacity: 2
CONFIGURATION
Model: Standard
Mechanical Central Lock
MP3 + Radio
Black Center Console Panel
Adjustable Steering Wheel
Rear View Mission- Manual Single Curvature
Cabin Painting- Normal
Door Handle - Black
Passengers Armrest - Fixed
Mechanical Central Lock
MP3 + Radio
Black Center Console Panel
Adjustable Steering Wheel
Rear View Mission- Manual Single Curvature
Cabin Painting- Normal
Door Handle - Black
Passengers Armrest - Fixed
| JMC BUSES JX6701VD 30 Seats | JX6606DA 23 Seats This vehicle has a classic appearance and a luxurious interior, which comes in two configurations of 23 seats and 30 seats. This bus meet the needs of business and passenger transportation.
|
| JMC BUSES JX6701VD 30 Seats | JX6606DA 23 Seats This vehicle has a classic appearance and a luxurious interior, which comes in two configurations of 23 seats and 30 seats. This bus meet the needs of business and passenger transportation.
|
SPECIFICATIONS
Enjine Model: Euro II JX6701VD
Type: 4 cylinders in line,4 strokes,water-cooling ,inter-cooling turbo diesel engine
Bore x stroke (mm): 93×102
Displacement (L) : 2.771
Compression Ratio: 17.2∶1
Max Horsepower KW(R/MIN): 85/3600
Max. Torque (N·m): 285/2000
Fuel Type: Diesel. GB252-2000
Rear Axle Type: Drive axle,press-welding axle housing. Reduction final drive is hypoid spiral bevel gear, single reduction
Final Reduction Ratio: 6.142
Model: JC528T2D
Transmission Type: Five-speed, forward gear with the synchromesh unit, mechanical
Clutch Type: Clutch, single, dry diaphragm spring, remote hydraulic control
Rim: 5.50F-16
Wheel: 7.00R16 12
Tire: Radial ply tyre 7.00R16 12 layer 7.00-16, Diagonal tyre 7.00-16, 12000kal/h
Air Conditioner: Environment-protected cooling capacity 1200kal/h
Dimensions (lxwxh) in mm:
30 Seats: 7005 × 2050 × 2640
23 Seats: 5955 x 1920 x 2750
Wheelbase: 3935
Fron/Rear Tread (m): 1655/1525
Minimum Turning Diameter: ≤17
Maximum Gradability: ≥25%
Maximum Speed:
30 Seats: 110
23 Seats: 100
Fuel Consumption/100km: 10
30 Seats: 10
23 Seats: 9
Ground Distance of First Step (mm): ≤410(Kurb Weight)
Aisle Width of Seats (kg): ≥720
Kurb Weight (kg): 3950
Maximum Total Weight:
30 Seats: 5900
23 Seats: 5345
Fuel Tank Capacity (L):
30 Seats: 90
23 Seats: 83
Type: 4 cylinders in line,4 strokes,water-cooling ,inter-cooling turbo diesel engine
Bore x stroke (mm): 93×102
Displacement (L) : 2.771
Compression Ratio: 17.2∶1
Max Horsepower KW(R/MIN): 85/3600
Max. Torque (N·m): 285/2000
Fuel Type: Diesel. GB252-2000
Rear Axle Type: Drive axle,press-welding axle housing. Reduction final drive is hypoid spiral bevel gear, single reduction
Final Reduction Ratio: 6.142
Model: JC528T2D
Transmission Type: Five-speed, forward gear with the synchromesh unit, mechanical
Clutch Type: Clutch, single, dry diaphragm spring, remote hydraulic control
Rim: 5.50F-16
Wheel: 7.00R16 12
Tire: Radial ply tyre 7.00R16 12 layer 7.00-16, Diagonal tyre 7.00-16, 12000kal/h
Air Conditioner: Environment-protected cooling capacity 1200kal/h
Dimensions (lxwxh) in mm:
30 Seats: 7005 × 2050 × 2640
23 Seats: 5955 x 1920 x 2750
Wheelbase: 3935
Fron/Rear Tread (m): 1655/1525
Minimum Turning Diameter: ≤17
Maximum Gradability: ≥25%
Maximum Speed:
30 Seats: 110
23 Seats: 100
Fuel Consumption/100km: 10
30 Seats: 10
23 Seats: 9
Ground Distance of First Step (mm): ≤410(Kurb Weight)
Aisle Width of Seats (kg): ≥720
Kurb Weight (kg): 3950
Maximum Total Weight:
30 Seats: 5900
23 Seats: 5345
Fuel Tank Capacity (L):
30 Seats: 90
23 Seats: 83
